Electric Ball Valve

Electric ball valves pair a standard ball valve with an electric actuator. Powered by a single‑phase or three‑phase supply, the actuator rotates the ball 90 degrees to open or close the flow.
Specific Applications
Electric ball valves are widely applied in natural gas systems, petrochemical plants, oil storage facilities, sticky media, light slurries, HVAC circulation, water treatment, food and pharmaceutical lines, as well as general industrial fluid systems.
Key Features
Precise Electric Actuation – Single‑phase or three‑phase power drives the ball to rotate 90°. This electric ball valve offers fast, reliable quarter‑turn operation. Choose on/off (switch type) or modulating (4‑20mA signal) for precise flow control.
Motorized Ready for Any System – Designed as a motorized ball valve for natural gas, petrochemical, oil storage, sticky media, light slurries, HVAC, water treatment, food/pharma, and general industrial fluids. Explosion‑proof versions (ExdIIBT4 / ExdIICT4) available for hazardous environments.
Zero Leakage & Ultra‑Low Flow Resistance – Full‑bore design reduces pressure drop. Seals: PTFE, reinforced PTFE, PPL, carbon fiber, or metal seat – supporting temperatures from -196°C up to 815°C and pressures PN1.6–42.0 MPa (Class150‑2500).
Wide Size & Material Range – Sizes DN15 to DN1200. Bodies: carbon steel WCB, stainless steel CF8/CF8M, brass, or alloy. End connections: flanged, threaded, or welded to DIN, ANSI, JIS, or BS. This electric ball valve accommodates nearly any pipeline specification.
Tested & Customizable – Factory high‑pressure, gas‑tight, and seat leakage tests. Special voltages, fail‑safe options, and remote control accessories are available on request.
Quality Certification
We hold ISO 9001, ISO 14001, and ISO 45001 certifications, plus a special equipment production license (TS).  Our products are made to API, ANSI, JIS, ISO, BS, JB, and GB standards. This covers material checks, non‑destructive testing, precise measurements, and valve strength/sealing performance.
Custom Manufacturing Services
You send us a drawing or sample, and we review the requirements. Then we confirm the drawing and give you a quote — faster if you provide a 3D model. After order confirmation, we schedule batch production.
