Self-Sealing Gate Valve

Self-sealing gate valves use the pressure of the line media itself to create a tighter seal. The higher the internal pressure, the tighter the closure. This design pushes the disc against the seat as pressure rises.
Where They Are Used
Self-sealing gate valves are commonly found in thermal power plants, petrochemical plants, high‑temperature and high‑pressure steam lines, and other severe services where reliable shut‑off is critical.
Key Features
Self-Sealing Design – The higher the line pressure, the tighter the seal. This Self-Sealing Gate Valve uses the media’s own pressure to energize the bonnet seal ring and push the disc against the seat – eliminating external leakage. Ideal for high‑pressure steam, thermal power, and petrochemical plants.
Built for Extreme Conditions – Available in WCB, forged/cast steel (A105, F22, F11, F91, F304, F316L). Engineered for oilfield, refinery, and high‑temperature applications. As a true Self-Sealing Gate Valve, its wedge‑type flexible or double disc compensates for thermal deformation to prevent sticking.
Reliable Shut‑Off & Thermal Relief – Designed for fully open or fully closed operation (no throttling). After full operation, turn the handwheel back half a turn to relieve thermal stress on the stem – extending valve life.
Multiple End Connections & Standards – Choose flanged, butt-welded, or threaded ends. Compliant with DIN, ANSI, JIS, BS, or GB. Every valve is pressure-tested, seat-tested, and visually inspected before shipment.
Customizable for Your Service – Body and trim materials selected per your pressure, temperature, and media. Special sizes available on request.
Quality Certification
We hold ISO 9001, ISO 14001, and ISO 45001 certifications, plus a special equipment production license (TS). Our products are made to API, ANSI, JIS, ISO, BS, JB, and GB standards. This covers material checks, non‑destructive testing, precise measurements, and valve strength/sealing performance.
Custom Manufacturing Services
You send us a drawing or sample, and we review the requirements. Then we confirm the drawing and give you a quote — faster if you provide a 3D model. After order confirmation, we schedule batch production.
